Eye Hooks for wire ropes

Features:

The most complete line of Eye hooks. Available ½ ton to 60 tons.

Proper design, careful forging and precision controlled quench and tempering give maximum strength.

Every Eye Hook has a pre-drilled cam which can be equipped with a latch.

Eye hooks are load rated.

Available in mild steel and alloy steel.

Note:

Proof load is 2 times Working Load Limit. All carbon hooks-average straightening load (ultimate load) is 5 times Working Load Limit. Alloy eye hooks

1 ton to 22 ton - average straightening load (ultimate load) is 4 timesWorking Load Limit. Alloy eye hooks 30

Straightening load (ultimate Load) is 4 times the Working Load Limit. All Alloy hooks- average straightening load (ultimate load) is 4 times Working Load Limit.

Quick Enquiry

Working Load Limit (Tons)	Dimensions (mm)
Carbon	Alloy	A	B	C	D	F	G	H	J	K	P	Q
8	1.25	110	37.3	81.5	73.0	31.8	19.1	20.1	20.1	14.2	51.0	19.0
1	1.6	125	44.5	93.5	81.0	35.1	21.3	23.9	23.9	15.8	57.0	23.1
1.6	2.5	141	51.5	104	92.0	38.1	25.4	29.5	29.5	19.1	64.0	28.7
2	3.2	162	61.0	119	104	41.4	28.5	33.3	33.3	21.3	72.0	31.8
3.2	5.4	201	74.5	147	125	51.0	36.6	41.2	41.2	28.5	90.5	39.6
5	8	256	97.0	187	165	63.5	46.0	52.0	52.0	35.1	113	51.0
7.5	12.5	316	119	230	192	76.0	57.0	66.5	66.5	41.2	140	62.0
10	16	354	137	255	221	82.5	65.5	74.5	74.5	49.3	157	72.0
15	22	434	168	318	279	108	75.5	89.0	89.0	60.5	186	89.0
20	30	495	178	357	346	127	92.0	117	117	76.0	223	89.0
25	37	630	216	462	357	137	116	127	127	92.0	289	114
30	45	697	236	511	392	152	129	140	140	94.5	321	125
40	60	821	273	602	470	178	152	165	165	113	376	145
